Wheel of Fate

Animals develop according to a programed pattern – they follow one line from head to tail, and another from back to belly. In fruit fly embryos this pattern of development is orchestrated by a protein called dorsal, which switches certain genes on and off. Dorsal levels are spread unevenly around the embryo’s girth. The amount determines which genes are expressed where, which in turn dictates the fate of new cells. This embryo cross section shows the system at work. Each colour represents a different gene. At the top, where there is least dorsal protein, a gene called dpp (stained yellow) is turned on. At the bottom, high concentrations of dorsal switch on another gene (red). So this fluorescent pinwheel helps scientists understand how the right sorts of cells end up in the right place.

Written by Daniel Cossins

Daniel Cossins

Writer

As a freelance science writer, Dan's work has been published in award-winning magazines including BBC Focus, Wired UK, Cosmos, BBC Knowledge, BBC History and Men's Health.

Website

• Angelike Stathopoulos
• California Institute of Technology, USA
• Copyright Elsevier 2012
• Published in Developmental Cell
